36" Island Hood Décor (Stainless Steel) - PUR98DSS
$2,699.00
Color : Clean Touch Steel
$2,699.00
Key Features
Safety turn off
Stainless-steel grease filters (10-layer)
Miele CleanCover
Available from DreamHome Appliance Group Inc, serving customers throughout .
Features
Safety turn off
The ventilation hood will switch off automatically after 10 hours. This ensures maximum safety even in case of operating errors.
Stainless-steel grease filters (10-layer)
Miele Ventilation Hoods are equipped with a 10-ply stainless-steel grease filter and guarantee a high-level of grease removal. During removal, the integrated fall protection ensures safe handling and protects your cooktop against damage. The top layer and the filter frame are made of high-quality stainless steel, meaning that there is no visible discoloration as a result of dishwasher cleaning and it retains its sleek appearance for a long time.
Miele CleanCover
Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. The CleanCover is also particularly easy to clean. Miele care and attention down to the very last detail for greater safety and convenience.
Specifications
General information
| Model number | PUR 98 D |
| Manufacturer material number | 10743130 |
| EAN number | 4002515940082 |
| Marketing class | Silver |
Design
| Island ventilation hood | TRUE |
| Color | Stainless steel |
Operating modes
| Recirculated mode | Can be retrofitted |
| Recirculation conversion kit (order separately) | DUI 32 |
| OdorFree charcoal filter (order separately) | DKF 12-P |
User convenience
| Electronic controls | TRUE |
| Operation | Light-touch switches with LEDs |
| Power levels (number excl. Intensive) | 3 |
| Booster levels | 1 |
| CleanCover | TRUE |
Cleaning convenience
| Easy-to-clean canopy interior – CleanCover | TRUE |
Filter system
| Number of dishwasher-safe stainless steel grease filters (10-ply) | 3 |
Lighting
| Number x W | 4 x 3 W |
| Light intensity in Lx | 500 lx |
| Color temperature in K | 3000 Kelvin |
Blower
| Dual-action blower | TRUE |
Exhaust air
| Air throughput in CFM in Booster | 507 |
| Air throughput with Booster level 1 (m³/h) according to EN 61591 | 506.18 (860) |
Safety
| Safety shut-off | TRUE |
Technical data
| Overall hood height for vented mode and external in inches (mm) | 27 1/4 (690)–39 (990) |
| Overall height for recirculation mode ventilation hoods in mm | 29 5/8 (750)–41 3/4 (1060) |
| Overall min. height for vented and external in in. (mm) | 27 1/4 (690) |
| Overall max. height for vented and external in in. (mm) | 39 (990) |
| Overall min. height for recirculation in in. (mm) | 29 5/8 (750) |
| Overall max. height for recirculation in in. (mm) | 41 3/4 (1060) |
| Canopy width in in. (mm) | 35 3/8 (898) |
| Canopy height in in. (mm) | 2 7/8 (70) |
| Depth of hood canopy in in. (mm) | 23 5/8 (598) |
| Minimum height above electric cooktops in mm | 24 1/8 (610) |
| Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm | 26 (660) |
| Net weight in lbs. (kg) | 75 (34.0) |
| Plug type | Without plug |
| Hard-wired | TRUE |
| Total connected load in kW | 0.362 |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Frequency in Hz | 60 |
| Number of phases | 1 |
Installation note
| Vent connection at top | TRUE |
| Diameter of vent connection in in. (mm) | 6 (150) |
| Telescopic chimney | TRUE |
Standard accessories
| Non-return flap | TRUE |
Dimensions & Weight
| Width | 35.35 in. |
| Height | - |
| Length | 23.54 in. |
| Weight | 165.25 lbs. |
| Gross Weight | 119.05 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 53.74 in. |
| Shipping Height | 32.48 in. |
| Shipping Length | 34.06 in. |
| Shipping Weight | 205.25 lbs. |
| Source | Manufacturer |
| Total of Shipping Weight | 205.25 lbs. |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 34.4 ft³ |
| Dimensional Weight | - |
| Total of Cubes | - |
| Total of Dimensional Weight | - |
| Cubic Feet Measurement | - |
